Connectors are common components in electronic devices that are used to connect circuits or transmit signals and power between devices.
The classification of connectors is very diverse, and can be classified according to the use and standards. This article covers connectors
The classification as well as the common connector types help you better choose and adapt the connector to your needs.
The classification of connectors can be carried out from the following dimensions, including connection mode, structural form, use, and so on
1. The connection method can be divided into two ways: plug and insert connection and welding connection.
Plug-and-pull connection refers to the connection between the connector and the circuit or device by inserting and pulling out. This connection method has the characteristics of convenience, fast, reusable, etc., suitable for frequent disassembly and replacement occasions. Common plug connectors include USB interface, HDMI interface, audio interface, and so on.
2. Welded connection refers to the connection between the connector and the circuit or device by welding. This connection method has the characteristics of stable, reliable, suitable for high frequency and high-speed transmission, and is suitable for occasions with high requirements for connection stability. Common welded connectors are D-type sub and female heads, board-to-board connectors, etc.
If you need any products, you can contact me in time, we have many styles.
Post time: Aug-16-2024
