(New)16mm Super short length body Latching push button switch(Length under 20mm)

Short Description:

1

Mounting Hole:  Φ16mm (19mm,22mm can be choose)
Switch Rating: 1A/24VDC
Contact Configuration: 1NO
Operation Type:  Maintained (Need Momentary pls contact us)
Operation Travel: 0.5mm
Terminal Type: wire leading 300mm
Switching:  A(Single-break contact)
Panel Thickness: 1~6mm
Torque: About 0.6Nm
Mechanical Life: 500,000 cycles
Electrical Life: 500,000 cycles
Button:  Stainless steel
Body:  Stainless steel
Base:  PBT
Operating Force:  About 3.8N(16mm),7.8N(19mm),5N(22mm)
IP Degree:  IP65,IK05
