ELEWIND 19mm Ring illuminated Momentary latching push button 12V waterproof (PM192F-□■E/J/△/▲/◎)

Short Description:

PM192F-□■E/J/△/▲/◎
Φ19mm Diameter
Switch Rating: Ith:5A, Ui:250V
Contact Configuration: 1NO1NC or 2NO2NC
Operation Type: Momentary OR Latching
Terminal Type(◆): Pin Terminal(J)
The shell Material: Stainless steel or black plated Aluminum alloy
Ring light Color(△): red green blue orange white yellow
Voltage: 1.8-220V
IP Degree: IP65 IK09


Product Detail

Product Tags

Product Parameters

Product Model: PM192F-□■E/J/△/▲/◎
Mounting Hole Size: 19MM
Switch Value:
Ith: 5A, UI: 250V
Operation Type: Momentary,Latching
Method Of Payment: T/T(Wire transfer), Paypal, Credit card
Available equipment: Elevators, charging piles, automation equipment, motor vehicles, yachts, access control, automatic guided vehicles, lathes, lifts, lawn mowers

QQwqf

Product Introduction

Metal push button, individually developed by our company, has dozens of proprietary intellectual property rights. There are many types, such as indicator, push button, latching push button, illuminated push button, selector, illuminated selector, key lock switch, emergency stop switch and buzzer. The integrity, strength and product quality of our company have been recognized by the industry. We take "pursues the perfect quality, being a dependable partner for customer" as the management idea. By taking the good faith as the foundation and the quality first as the principles, we are willing to make progress with dear customers and create great achievements together!Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs. We warmly welcome clients at home and abroad to discuss cooperation and create a better future! It is our greatest honor to cooperate with you!

Hot selling PM192F series metal vandal resistant led ring light solid 1no1nc ,2NO2NC push button switch. 304 stainless steel metal buttons are durable and waterproof. This is the 19mm self-resetting or locking button, Wide range of panel thicknesses. You can mount them to the corresponding panel holes. At the same time, when you buy, we will send the corresponding number of waterproof rubber gaskets, which can prevent water from entering the shell. The button have six color ring Illuminated light(red green white yellow orange blue can choose).
